Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R922 1-216-045-00 METAL CHIP 680 5% 1/10W
R923 1-216-045-00 METAL CHIP 680 5% 1/10W
R924 1-216-049-11 RES, CHIP 1K 5% 1/10W
R925 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R926 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R927 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R928 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R929 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R930 1-216-295-00 SHORT (CHIP) 0
R931 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R932 1-216-073-00 METAL CHIP 10K 5% 1/10W
R951 1-216-041-00 METAL CHIP 470 5% 1/10W
R952 1-216-109-00 METAL CHIP 330K 5% 1/10W
R953 1-216-049-11 RES, CHIP 1K 5% 1/10W
R954 1-216-049-11 RES, CHIP 1K 5% 1/10W
R955 1-216-049-11 RES, CHIP 1K 5% 1/10W
R956 1-216-049-11 RES, CHIP 1K 5% 1/10W
R957 1-216-073-00 METAL CHIP 10K 5% 1/10W
R958 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R959 1-216-073-00 METAL CHIP 10K 5% 1/10W
R960 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R961 1-216-037-00 METAL CHIP 330 5% 1/10W
R962 1-216-033-00 METAL CHIP 220 5% 1/10W
R963 1-216-029-00 METAL CHIP 150 5% 1/10W
R964 1-216-025-00 RES, CHIP 100 5% 1/10W
R965 1-216-037-00 METAL CHIP 330 5% 1/10W
R966 1-216-033-00 METAL CHIP 220 5% 1/10W
R967 1-216-029-00 METAL CHIP 150 5% 1/10W
R968 1-216-021-00 METAL CHIP 68 5% 1/10W
R969 1-216-029-00 METAL CHIP 150 5% 1/10W
R970 1-216-021-00 METAL CHIP 68 5% 1/10W
R971 1-216-029-00 METAL CHIP 150 5% 1/10W
R972 1-216-021-00 METAL CHIP 68 5% 1/10W
R981 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R982 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R983 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R984 1-216-081-00 METAL CHIP 22K 5% 1/10W
< SWITCH >
SW951 1-762-937-11 SWITCH, ROTARY (D-BASS)
***********************************************************
* A-3313-459-A MAIN BOARD, COMPLETE
(XR-C5100R:AEP, UK, South European)
* A-3313-463-A MAIN BOARD, COMPLETE
(XR-C5100R: German)
* A-3313-475-A MAIN BOARD, COMPLETE (XR-C5103R)
*********************
(Including POWER BOARD, COMPLETE)
* 3-018-613-01 HEAT SINK
* 3-018-798-01 BRACKET (IC)
* 3-019-148-01 BRACKET (HS) (M)
7-685-794-09 SCREW +PTT 2.6X10 (S)
7-685-796-09 SCREW +PTT 2.6X14 (S)
< CAPACITOR >
C1 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C2 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C3 1-126-157-11 ELECT 10uF 20% 16V
C4 1-126-157-11 ELECT 10uF 20% 16V
C5 1-126-157-11 ELECT 10uF 20% 16V
C6 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C9 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C11 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C12 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C13 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C14 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C15 1-124-584-00 ELECT 100uF 20% 10V
C16 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C17 1-124-463-00 ELECT 0.1uF 20% 50V
C18 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C19 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C20 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C21 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C22 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C23 1-126-933-11 ELECT 100uF 20% 16V
C24 1-163-099-00 CERAMIC CHIP 18PF 5% 50V
C25 1-163-099-00 CERAMIC CHIP 18PF 5% 50V
C26 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C28 1-126-157-11 ELECT 10uF 20% 16V
C29 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C30 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C31 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C32 1-126-160-11 ELECT 1uF 20% 50V
C34 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C35 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C36 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(XR-C5100R)
C38 1-124-584-00 ELECT 100uF 20% 10V
(XR-C5103R)
C39 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
(XR-C5103R)
C101 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C102 1-126-160-11 ELECT 1uF 20% 50V
C103 1-126-160-11 ELECT 1uF 20% 50V
C111 1-126-160-11 ELECT 1uF 20% 50V
C112 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C113 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C114 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C115 1-164-492-11 CERAMIC CHIP 0.15uF 10% 16V
C116 1-164-492-11 CERAMIC CHIP 0.15uF 10% 16V
C118 1-126-157-11 ELECT 10uF 20% 16V
C119 1-126-157-11 ELECT 10uF 20% 16V
C120 1-126-157-11 ELECT 10uF 20% 16V
C121 1-126-157-11 ELECT 10uF 20% 16V
C122 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C123 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C124 1-126-096-11 ELECT 10uF 20% 35V
C151 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C152 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C153 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C155 1-124-234-00 ELECT 22uF 20% 16V
C157 1-124-584-00 ELECT 100uF 20% 10V
C158 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C201 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C202 1-126-160-11 ELECT 1uF 20% 50V
C203 1-126-160-11 ELECT 1uF 20% 50V
KEY MAIN
