– 45 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R602 1-216-097-00 RES, CHIP 100K 5% 1/10W
R603 1-216-089-00 RES, CHIP 47K 5% 1/10W
R604 1-216-089-00 RES, CHIP 47K 5% 1/10W
R606 1-216-206-00 RES, CHIP 2.2K 5% 1/8W
R607 1-216-073-00 METAL CHIP 10K 5% 1/10W
R608 1-216-097-00 RES, CHIP 100K 5% 1/10W
R609 1-216-037-00 METAL CHIP 330 5% 1/10W
R610 1-216-073-00 METAL CHIP 10K 5% 1/10W
R612 1-216-025-00 RES, CHIP 100 5% 1/10W
R613 1-216-025-00 RES, CHIP 100 5% 1/10W
R614 1-208-806-11 RES, CHIP 10K 0.50% 1/10W
R615 1-208-806-11 RES, CHIP 10K 0.50% 1/10W
R616 1-216-295-00 SHORT (CHIP) 0
R617 1-216-025-00 RES, CHIP 100 5% 1/10W
R618 1-208-806-11 RES, CHIP 10K 0.50% 1/10W
R619 1-208-806-11 RES, CHIP 10K 0.50% 1/10W
R620 1-216-025-00 RES, CHIP 100 5% 1/10W
R621 1-216-025-00 RES, CHIP 100 5% 1/10W
R624 1-249-383-11 CARBON 1.5 5% 1/6W
R625 1-249-383-11 CARBON 1.5 5% 1/6W
R626 1-249-383-11 CARBON 1.5 5% 1/6W
R627 1-249-383-11 CARBON 1.5 5% 1/6W
R660 1-216-198-00 RES, CHIP 1K 5% 1/8W
R661 1-216-129-00 METAL CHIP 2.2M 5% 1/10W
R704 1-216-246-00 RES, CHIP 100K 5% 1/8W
R705 1-216-073-00 METAL CHIP 10K 5% 1/10W
R706 1-216-025-00 RES, CHIP 100 5% 1/10W
R707 1-216-174-00 RES, CHIP 100 5% 1/8W
R708 1-216-017-00 RES, CHIP 47 5% 1/10W
< VARIABLE RESISTOR >
RV1 1-241-768-11 RES, ADJ, CARBON 220K
< SWITCH >
S601 1-692-431-21 SWITCH, TACTILE (RESET)
< TUNER >
TU1 1-693-373-11 TUNER UNIT FAE338-A01 (FM/AM)
(XR-C5100R)
TU1 A-3282-031-A TUNER UNIT TUX-006/2 (EE) (FM/AM)
(XR-C5103R)
< VIBRATOR >
X1 1-567-848-11 VIBRATOR, CRYSTAL (7.2MHz)
X2 1-579-242-41 VIBRATOR, CRYSTAL (4.332MHz)
X501 1-579-125-11 VIBRATOR, CERAMIC (8MHz)
X502 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
************************************************************
* A-3313-456-A POWER BOARD, COMPLETE
***********************
(Included in MAIN BOARD, COMPLETE)
< CAPACITOR >
C801 1-126-096-11 ELECT 10uF 20% 25V
C802 1-126-096-11 ELECT 10uF 20% 25V
C803 1-124-589-11 ELECT 47uF 20% 16V
C804 1-124-589-11 ELECT 47uF 20% 16V
C805 1-136-165-00 FILM 0.1uF 5% 50V
C807 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C811 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C812 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C813 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C814 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C821 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C822 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C823 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C824 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
< CONNECTOR >
CN801 1-778-985-11 PIN, CONNECTOR (ISO)
CN802 1-778-983-11 PIN, CONNECTOR (PC BOARD) 13P
CN803 1-778-983-11 PIN, CONNECTOR (PC BOARD) 13P
< DIODE >
D801 8-719-049-38 DIODE 1N5404TU
D813 8-719-970-02 DIODE 1SR139-400
D814 8-719-970-02 DIODE 1SR139-400
D815 8-719-970-02 DIODE 1SR139-400
D816 8-719-970-02 DIODE 1SR139-400
D823 8-719-970-02 DIODE 1SR139-400
D824 8-719-970-02 DIODE 1SR139-400
D825 8-719-970-02 DIODE 1SR139-400
D826 8-719-970-02 DIODE 1SR139-400
< IC >
IC801 8-759-490-74 IC TDA7384
< SHORT >
JC801 1-216-296-00 SHORT (CHIP) 0
JC802 1-216-296-00 SHORT (CHIP) 0
JC803 1-216-295-00 SHORT (CHIP) 0
< COIL >
L801 1-416-046-11 INDUCTOR 400uH
< RESISTOR >
R801 1-216-198-00 RES, CHIP 1K 5% 1/8W
R802 1-216-198-00 RES, CHIP 1K 5% 1/8W
R803 1-216-049-11 RES, CHIP 1K 5% 1/10W
R804 1-216-049-11 RES, CHIP 1K 5% 1/10W
< SWITCH >
S801 1-571-478-11 SWITCH, SLIDE (POWER SELECT)
************************************************************
MISCELLANEOUS
**************
16 1-782-092-11 CORD (WITH CONNECTOR) (ISO-P) (POWER)
17 1-782-093-11 CORD (WITH CONNECTOR) (ISO-S) (SPEAKER)
18 1-777-989-41 CORD (WITH CONNECTOR) (AMP REM/ATT)
F801 1-532-877-11 FUSE (BLADE TYPE) (AUTO FUSE) (10A)
HP901 1-500-196-21 HEAD, MAGNETIC (PLAYBACK)
M901 A-3291-665-A MOTOR ASSY, MAIN (CAPSTAN/REEL)
************************************************************
MAIN POWER
