– 50 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R951 1-216-041-00 METAL CHIP 470 5% 1/10W
R953 1-216-121-00 RES,CHIP 1M 5% 1/10W
R954 1-216-049-11 RES,CHIP 1K 5% 1/10W
R955 1-216-049-11 RES,CHIP 1K 5% 1/10W
R956 1-216-049-11 RES,CHIP 1K 5% 1/10W
R957 1-216-109-00 METAL CHIP 330K 5% 1/10W
R961 1-216-029-00 METAL CHIP 150 5% 1/10W
R962 1-216-021-00 METAL CHIP 68 5% 1/10W
R963 1-216-037-00 METAL CHIP 330 5% 1/10W
R964 1-216-033-00 METAL CHIP 220 5% 1/10W
R965 1-216-037-00 METAL CHIP 330 5% 1/10W
R966 1-216-033-00 METAL CHIP 220 5% 1/10W
R967 1-216-037-00 METAL CHIP 330 5% 1/10W
R968 1-216-033-00 METAL CHIP 220 5% 1/10W
R969 1-216-037-00 METAL CHIP 330 5% 1/10W
R970 1-216-033-00 METAL CHIP 220 5% 1/10W
R975 1-216-037-00 METAL CHIP 330 5% 1/10W
R976 1-216-029-00 METAL CHIP 150 5% 1/10W
R977 1-216-037-00 METAL CHIP 330 5% 1/10W
R981 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R982 1-216-663-11 METAL CHIP 3.3K 0.5% 1/10W
R983 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
R984 1-216-081-00 METAL CHIP 22K 5% 1/10W
R990 1-216-295-00 SHORT 0
R991 1-216-295-00 SHORT 0
< ROTARY ENCODER >
RE901 1-475-014-11 ENCODER, ROTARY (VOLUME/BASS/
TREBLE/BALANCE/FADER CONTROL)
< SWITCH >
S901 1-771-290-11 SWITCH, SLIDE
(+ ) +, – 0 =: SEEK/AMS)
S981 1-762-937-11 SWITCH, ROTARY (D-BASS)
************************************************************
* A-3317-345-A MAIN BOARD, COMPLETE
(XR-C5120R: AEP, UK, South European)
* A-3317-346-A MAIN BOARD, COMPLETE
(XR-C5120R: German)
* A-3317-351-A MAIN BOARD, COMPLETE
(XR-C5110R: AEP, UK, South European)
* A-3317-352-A MAIN BOARD, COMPLETE
(XR-C5110R: German)
*********************
* 3-019-147-01 BRACKET (IC) (M)
* 3-031-050-01 HEAT SINK
* 3-031-828-01 BRACKET (REG.IC)
7-685-793-09 SCREW +PTT 2.6X8 (S)
7-685-795-09 SCREW +PTT 2.6X12 (S)
< CAPACITOR >
C1 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C2 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C3 1-124-233-11 ELECT 10uF 20% 16V
C4 1-124-233-11 ELECT 10uF 20% 16V
C5 1-124-233-11 ELECT 10uF 20% 16V
C6 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C7 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C8 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C10 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C11 1-163-020-00 CERAMIC CHIP 0.0082uF 10% 50V
C12 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C13 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C14 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C15 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C16 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C17 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C18 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C19 1-163-059-91 CERAMIC CHIP 0.01uF 10% 50V
C20 1-124-234-00 ELECT 22uF 20% 16V
C21 1-163-091-00 CERAMIC CHIP 8PF 50V
C22 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C23 1-163-087-00 CERAMIC CHIP 4PF 50V
C24 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C25 1-124-233-11 ELECT 10uF 20% 16V
C26 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C27 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C51 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C52 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C53 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C54 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C55 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C56 1-124-234-00 ELECT 22uF 20% 16V
C57 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C58 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C59 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C60 1-163-135-00 CERAMIC CHIP 560PF 5% 50V
C61 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C62 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C63 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C64 1-124-233-11 ELECT 10uF 20% 16V
C71 1-124-234-00 ELECT 22uF 20% 16V
C73 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C81 1-124-589-11 ELECT 47uF 20% 16V
C82 1-124-234-00 ELECT 22uF 20% 16V
C83 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C90 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C91 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C92 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C93 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C94 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C95 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C96 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C97 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C98 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C101 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C102 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C105 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C107 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C108 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C110 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C111 1-126-163-11 ELECT 4.7uF 20% 50V
C121 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C122 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C123 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C135 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
KEY MAIN
