– 51 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C141 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C142 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C151 1-163-020-00 CERAMIC CHIP 0.0082uF 10% 50V
C152 1-124-257-00 ELECT 2.2uF 20% 50V
C153 1-124-257-00 ELECT 2.2uF 20% 50V
C171 1-126-163-11 ELECT 4.7uF 20% 50V
C173 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C174 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C181 1-126-163-11 ELECT 4.7uF 20% 50V
C182 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C183 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C184 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C201 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C202 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C205 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C207 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C208 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C210 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C211 1-126-163-11 ELECT 4.7uF 20% 50V
C235 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C241 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C242 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C251 1-163-020-00 CERAMIC CHIP 0.0082uF 10% 50V
C252 1-124-257-00 ELECT 2.2uF 20% 50V
C253 1-124-257-00 ELECT 2.2uF 20% 50V
C271 1-126-163-11 ELECT 4.7uF 20% 50V
C273 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C274 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C281 1-126-163-11 ELECT 4.7uF 20% 50V
C282 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C283 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C284 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C301 1-124-584-00 ELECT 100uF 20% 10V
C302 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C303 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C304 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C305 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C306 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C331 1-124-234-00 ELECT 22uF 20% 16V
C361 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C362 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C363 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C364 1-126-157-11 ELECT 10uF 20% 16V
C365 1-124-234-00 ELECT 22uF 20% 16V
C366 1-126-934-11 ELECT 220uF 20% 16V
C401 1-124-584-00 ELECT 100uF 20% 10V
C402 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C404 1-124-233-11 ELECT 10uF 20% 16V
C405 1-124-234-00 ELECT 22uF 20% 16V
C408 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C409 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C502 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C503 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C504 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C505 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C506 1-163-102-00 CERAMIC CHIP 24PF 5% 50V
C507 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C509 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C510 1-124-584-00 ELECT 100uF 20% 10V
C511 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C527 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C571 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(C5120R)
C601 1-107-885-31 ELECT 3300uF 20% 16V
C602 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C603 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C611 1-124-233-11 ELECT 10uF 20% 16V
C612 1-124-233-11 ELECT 10uF 20% 16V
C613 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C614 1-107-909-11 ELECT 47uF 20% 16V
C616 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C617 1-136-165-00 FILM 0.1uF 5% 50V
C621 1-124-589-11 ELECT 47uF 20% 16V
C622 1-124-257-00 ELECT 2.2uF 20% 50V
C623 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C631 1-164-222-11 CERAMIC CHIP 0.22uF 25V
C632 1-164-222-11 CERAMIC CHIP 0.22uF 25V
C641 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C653 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C654 1-125-701-11 DOUBLE LAYER 0.047F 0 5.5V
C655 1-126-933-11 ELECT 100uF 20% 16V
C661 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C671 1-126-157-11 ELECT 10uF 20% 16V
C672 1-126-157-11 ELECT 10uF 20% 16V
C673 1-126-157-11 ELECT 10uF 20% 16V
C674 1-126-157-11 ELECT 10uF 20% 16V
C675 1-126-157-11 ELECT 10uF 20% 16V
C676 1-126-157-11 ELECT 10uF 20% 16V
C701 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C702 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C703 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C704 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN301 1-766-260-11 CONNECTOR, FFC/FPC (ZIF) 7P
* CN302 1-506-995-11 PIN, CONNECTOR (PC BOARD) 13P
CN500 1-785-772-11 PLUG, CONNECTOR 15P
CN601 1-785-761-11 PIN, CONNECTOR (ISO)
CN701 1-580-907-31 PLUG, CONNECTOR (BUS CONTROL IN)
< JACK >
CNJ151 1-774-699-12 JACK, PIN 4P (BUS AUDIO IN, AUDUO OUT)
< DIODE >
D1 8-719-991-65 DIODE SB02W03C
D61 8-719-422-12 DIODE MA8039
D71 8-719-158-15 DIODE RD5.6S-B
D81 8-719-977-28 DIODE DTZ10B
D90 8-719-404-50 DIODE MA111-TX
D91 8-719-404-50 DIODE MA111-TX
D92 8-719-976-99 DIODE DTZ5.1B
D93 8-719-422-12 DIODE MA8039
D361 8-719-977-22 DIODE DTZ9.1
D362 8-719-911-19 DIODE 1SS119
MAIN
Ver 1.1
