5GB
Parts for Connection and
Installation
This parts list does not include all the package
contents.
Connection
Please read all the connection procedures carefully
before making any connections.
• This unit is designed for negative ground (earth)
12 V DC operation only.
• Do not operate the subwoofer on a weak battery
as the subwoofer requires a good power supply
for optimum performance.
• Before making any connections, disconnect the
ground (earth) terminal of the car battery to avoid
short circuits.
• Connect this unit to the +12 V power supply lead
only after all other leads have been connected.
• If your car is equipped with a computer system for
a purpose such as navigation, disconnecting the
ground (earth) lead from the car battery may
damage the computer memory. Leave the ground
(earth) lead connected and connect this unit to
the +12 V power supply lead only after all other
leads have been connected to prevent short
circuits.
Connection and Installation
Power supply leads (1) Mounting bracket (4)
Securing screw
(5 × 8 mm (
7
/32 ×
11
/32 in)) (4)
Mounting screw
(5 × 20 mm
(
7
/32 ×
13
/16 in)) (4)
Mounting bracket (1) Securing screw
(2 × 5 mm (
3
/32 ×
7
/32 in)) (2)
Mounting screw
(3 × 12 mm (
1
/8 ×
1
/2 in)) (2)
Double-sided tape (1)
Power Connections
To Next Page
