MEGA BASS indicator (white)
STAMINA indicator (white)
GUITAR indicator (white)
ECHO indicator (white)
KEY CONTROL
(flat) indicator (white)
Slow
flashing
The speaker is waiting for a BLUETOOTH device to connect to.
Lit The sound effect is set to MEGA BASS.
Unlit The sound effect is set to other than MEGA BASS.
Lit The sound effect is set to STAMINA.
Unlit The sound effect is set to other than STAMINA.
Lit The speaker is in guitar mode.
Unlit The speaker is not in guitar mode.
Lit The microphone echo level is set to 1, 2, or 3.
Unlit
The microphone echo effect is not activated or no microphone is connected to the speaker.
While the microphone echo level is set to 3, pressing the ECHO button behind the cap on the rear side
of the speaker deactivates the microphone echo effect and turns off the indicator.
Flashing
While the microphone echo level is set to 1 or 2, pressing the ECHO button behind the cap on the rear side
of the speaker makes the indicator flash once.
