Sorelle 1050 - Dresser Organizer Assembly

9
ASSEMBLY
5. Insert wooden peg on Small Front Support Bar
(H) into opening and (C-4) on Middle Side Panel
(A) and secure with Bolt (F). Figure 5
.
5
(F)
(H)
(A)
8. Insert Support Bar Solid Ends (C-1) and attach
Right End (B) with each support bar on Left Side
Rail (A). Figure 8.
8
(B)
(A)
(C-1)
7. Insert Bottom Shelf (I) into grooves on middle
and back bottom braces. Figure 7.
7
(I)
(F) (x2)
6. Lay Middle Panel (A) on its side. Insert
Front Support Bar w/groove (C-2) into notch
on Middle Panel (A) and slide Dresser Top (E)
into top grooves. Slide Organizer Middle (D)
into grooves. Figure 6.
6
(E)
(D)
(A)
(C-3)
(C-2)
(F)
(C-4)
