Assembly instructions
Compact-Line kit
www.sorotec.de V 2.1.0
Illustration Description Num-
ber
plate Z
CL.FT.003.01
1
portal beam below
see page 6
1
portal cheek:
1)
:
left
23l
CL.FT.010.01
right
23r
CL.FT.011.01
1
1
Reference switch
with shim
EZB.T1 / AL.IS.001
3
switch carrier X
CL.FT.013.01
1
switch carrier Y
CL.FT.012.01
1
sled Y
CL.FT.017.01
1
face plate in the back
see page 6
1
front plate
see page 6
1
table top (pre-assembled)
see page 6
1
21
22
23
24
25
26
27
29
30
Illustration Description Num-
ber
angle 40x40
with cover cap
AL.PR.WS.084040
6
angle 45x45
AL.PR.WS.104545
4
portal beam (pre-ass.)
see page 6
1
timing belt Y
CL.ZAN.HTD3M100.300
1
belt wheel 36 teeth
bore 8 mm
AL.ZAN.HTD3M36.15.08
1
belt wheel 36 Zähne
bore 10 mm
CL.ZAN.HTD3M36.15.10
1
foot holder
CL.FT.018.01
1
drag chain holder
CL.FT.032.01
1
mounting bracket
for drag chain
CL.PR.BW.604020
1
cylindrical pin DIN6325
5x18 M6
AL.ZS.05.18
9
1)
Teile zur Portalerhöhung siehe Seite 6
31
32
33
34
35
36
37
38
39
Z
