Assembly instructions
Compact-Line kit
www.sorotec.de V 2.1.0
Order numbers of size-dependent parts
Machine
Description CL 04XX CL 06XX CL 08XX CL 10XX
4
ball screw X
incl. nut (16 x 10)
CL.ZAN.KGS1610.0600KH CL.ZAN.KGS1610.0800KH CL.ZAN.KGS1610.1000KH CL.ZAN.KGS1610.1200KH
4
ball screw X
incl. nut (16 x 5)
CL.ZAN.KGS1605.0600KH CL.ZAN.KGS1605.0800KH CL.ZAN.KGS1605.1000KH CL.ZAN.KGS1605.1200KH
15
linear rail X CL.ZFS.HGR20R.0588 CL.ZFS.HGR20R.0788 CL.ZFS.HGR20R.0988 CL.ZFS.HGR20R.1188
CL XX03 CL XX04 CL XX05 CL XX07
5
ball screw Y
incl. nut (16 x 10)
CL.ZAN.KGS1610.0450KH CL.ZAN.KGS1610.0550KH CL.ZAN.KGS1610.0650KH BL.ZAN.KGS1610.0850KH
5
ball screw Y
incl. nut (16 x 5)
CL.ZAN.KGS1605.0450KH CL.ZAN.KGS1605.0550KH CL.ZAN.KGS1605.0650KH BL.ZAN.KGS1605.0850KH
16
linear rail Y above CL.ZFS.HGR20R.0419 CL.ZFS.HGR20R.0519 CL.ZFS.HGR20R.0619 CL.ZFS.HGR20R.0819
17
linear rail Y below CL.ZFS.HGR20R.0478 CL.ZFS.HGR20R.0578 CL.ZFS.HGR20R.0678 CL.ZFS.HGR20R.0878
22
portal beam below CL.FT.026.01 CL.FT.027.01 CL.FT.028.01 CL.FT.055.01
28
face plate in the back CL.FT.020.01 CL.FT.021.01 CL.FT.022.01 CL.FT.053.01
29
front plate CL.FT.023.01 CL.FT.024.01 CL.FT.025.01 CL.FT.054.01
33
portal beam pre-ass. CL.FT.033.01 CL.FT.034.01 CL.FT.035.01 CL.FT.052.01
CL 0403 CL 0404 CL 0405 CL 0604
30
table top
(pre-assembled)
CL.FT.036.01 CL.FT.037.01 CL.FT.038.01 CL.FT.040.01
CL 0605 CL 0804 CL 0805 CL 1005
CL.FT.041.01 CL.FT.043.01 CL.FT.044.01 CL.FT.045.01
CL 1007
CL.FT.056.01
Order numbers for gantry elevation parts
• Portal cheek left CL.FT.046.01
• Portal cheek right CL.FT.047.01
• Plate Z axis CL.FT.048.01
• Bracing Z-axis left CL.FT.049.01
• Bracing Z-axis right CL.FT.050.01
• Ball screw including nut CL.ZAN.KGS1605.0320KH
• Linear guide rail short CL.ZFS.HGR20R.0274
• Linear guide rail long CL.ZFS.HGR20R.0370
