DAB950 / English Instruction Manual
1
UNPACKING
Remove all packing from the unit. Retain the packaging if you dispose of it please do so
according to local regulations.
 Main unit
 Remote Control (RC)
 2 AAA batteries
 3.5mm to 3.5mm cable
 AC Power Cord
 Instruction manual
PRODUCT OVERVIEW
FRONT VIEW
1
Remote Sensor
2
Display
3
Standby indicator
4
Disc Door
TOP VIEW
REAR VIEW
12
5V 1A output
13
AUDIO input
14
USB
15
Earphone
16
Power switch
17
AC input
5
Power on / off, Select Source
6
V-/+
Volume Control
7
Skip and search backward
8
Skip and search forward
9
“PAIR”
Pairing function in BT
10
Play / Pause
11
Eject
