SOUNDMASTER MCD9600BT - Rear Panel Connections; System Connection Diagram; Remote Control

Rear view
2.
2.
2.
2. SYSTEM
SYSTEM
SYSTEM
SYSTEM CONNECTION
CONNECTION
CONNECTION
CONNECTION DIAGRAM
DIAGRAM
DIAGRAM
DIAGRAM
3.
3.
3.
3. REMOTE
REMOTE
REMOTE
REMOTE CONTROL
CONTROL
CONTROL
CONTROL
1. FM aerial terminal (75 Ω )
2. Speaker Connectors
3. Main Lead
1. STANDBY BUTTON
2. STOP BUTTON
3. PLAY BUTTON
4. PROG BUTTON
5. REPEAT BUTTON
6. RANDOM BUTTON
7. INTRO BUTTON
8. REVERSE SEARCH BUTTON
9. FORWARD SEARCH BUTTON
10. CD /USB BUTTON
11. FOLDER+/ UP BUTTON
12. PRESET-/LEFT BUTTON
13. ST/MO BUTTON
14. MUTE BUTTON
15. SNOOZE BUTTON
3
16. SET BUTTON
17. ALARM BUTTON
18. OPEN/CLOSE BUTTON
19. PAUSE BUTTON
20. NUMERICAL BUTTONS
21. BLUE-PLAY/PAUSE BUTTON
( BLUETOOTH FUNCTION SPECIAL ) )
22. NEXT TRACK BUTTON
23. PREVIOUS TRACK BUTTON
24. MEM BUTTON
25. PRESET+/RIGHT BUTTON
26. FOLDER-/DOWN BUTTON
27. EQ BUTTON
28. VOLUME-/+ BUTTON
29. INPUT BUTTON
30. SLEEP BUTTON
FM AERIAL
