Identification of Controls
Main Unit
Insert the battery
Remove battery during storage or when you are not using the DVD
player for a long time.
2.Insert battery.
N
NOTES:
1.Open the battery door.
4
6.MODE
7.SETUP
8. PLAY/ PAUSE
9.OPEN
10. SD/MMC/MS
11. USB
12. Earphone Socket
13. AV OUT
14. COAXIAL
15. ON/OFF
16. DC IN 9-12V
17. ANT.
1.DVD/DVB
2.SOURCE
3.VOL- / VOL+
4.ENTER
5. / next / right
/ prev / left
/ forward / up
/ backward / down
short press is up/right/down/left;
long press is forward/next/
backward/prev.
10
11
12 13 14 15 16
1
2
3
4
9
7
5
6
8
17
