Soundoff Signal nFORCE ENFSSS**-Single Series User Manual

1.800.338.7337 / www.soundoffsignal.com
3
ENFSLXSS 11.14
FUNCTION TABLE 1
WIRE LIGHT
RED (SGL)
ORANGE (DUAL)
R/W (SGL)
O/W (DUAL)
WHT (SGL)
YELLOW (DUAL)
SINGLE DUAL TRI
+12V FLASH FLASH DUAL FLASH TRI
+12 CRUISE STEADY CLR 2 STEADY CLR 3
+12V +12V FLASH STEADY CLR 2 STEADY CLR 3
+12V NO OP NO OP NO OP
+12V +12V LOW PWR FLASH FLASH CLR 1 FLASH CLR 1
+12V +12V CRUISE FLASH CLR 2
FLASH CLR 2
+12V +12V +12V LOW PWR FLASH FLASH CLR 1 & 2
FLASH CLR 3
FUNCTION TABLE 2
WIRE LIGHT
RED (SGL)
ORANGE (DUAL)
R/W (SGL)
O/W (DUAL)
WHT (SGL)
YELLOW (DUAL)
SINGLE DUAL TRI
+12V FLASH FLASH CLR 1 FLASH CLR 1 & 2
+12V +12V CRUISE FLASH CLR 1 & 2 FLASH CLR 1, 2 & 3
+12V STEADY CLR 1 STEADY CLR 2 STEADY CLR 3
+12V +12V STEADY CLR 1 STEADY CLR 2 STEADY CLR 3
+12V +12V +12V STEADY CLR 1 STEADY CLR 2 STEADY CLR 3
+12V NO OP NO OP NO OP
FUNCTION TABLE 3
WIRE LIGHT
RED (SGL)
ORANGE (DUAL)
R/W (SGL)
O/W (DUAL)
WHT (SGL)
YELLOW (DUAL)
SINGLE DUAL TRI
+12V FLASH FLASH DUAL FLASH CLR 1, 2 & 3
+12V FLASH LOW PWR
FLASH CLR 1 & 2
LOW PWR
FLASH CLR 1, 2 & 3
LOW PWR
+12V +12V FLASH LOW PWR
FLASH COLOR 1 & 2
LOW PWR
FLASH CLR 1, 2 & 3
LOW PWR
+12V NO OP NO OP NO OP
+12V +12V FLASH LOW PWR
FLASH COLOR 1 & 2
LOW PWR
FLASH CLR 1, 2 & 3
LOW PWR
+12V +12V FLASH LOW PWR
FLASH COLOR 1 & 2
LOW PWR
FLASH CLR 1, 2 & 3
LOW PWR
+12V +12V +12V FLASH LOW PWR
FLASH COLOR 1 & 2
LOW PWR
FLASH CLR 1, 2 & 3
LOW PWR
FUNCTION TABLES
Changing the function table is only enabled when the LED module is in a flashing mode (disabled in cruise or steady ON functions). The functional operation of the LED module can be changed while applying the +V to the Red or Orange wire
with the black wire connected to ground. When the light is flashing, momentarily connect the White or Yellow wire to ground for >4S and <5S (light will go steady high, steady low, off, steady high, steady low) then release. The function
table will now advance to the next table (table 1 to table 2, table 2 to table 3, or table 3 to table 1). Repeat above process until required function table is active.
