REMOTE MODE: FOR USE WITH bluePRINT SYSTEM ONLY
Connecting the Green or Blue wire to ground before applying power to the Orange, Orange/White, Red or Red/White wires will place the LED module into remote mode and the light output color will be directly controlled by the input wires as
shown below.
For Cruise mode or Low Power control of the LED module, the signal to the control wires must be 100 +/- 2Hz using the duty cycle inputs listed below to produce the light output.
Cruise Mode Duty Cycle
(@ 100Hz)
Input Light Output
40% OFF
50% 5%
60% 10%
Low Power Flash D.C.
(@ 100Hz)
Input Light Output
70% 30%
80% 40%
90%
50%
nFORCE Secondary LED Light Remote Mode Functionality
Red or
Orange
Wire
Red/Wht
or Orange/
Wht Wire
Single Color Dual Color Tri Color
Color
Swap=OFF
Color
Swap=ON
Color
Swap=OFF
Color
Swap=ON
Color
Swap=OFF
Color
Swap=ON
Cruise - Cruise Color 1 Cruise Color 1 Cruise Color 2 Cruise Color 1 Cruise Color 2
- Cruise Cruise Color 2 Cruise Color 1 Cruise Color 2 Cruise Color 1
Cruise Cruise Cruise Color 2 Cruise Color 1 Cruise Color 3 Cruise Color 3
Flash - Flash Color 1 Flash Color 1 Flash Color 2 Flash Color 1 Flash Color 2
- Flash Flash Color 2 Flash Color 1 Flash Color 2 Flash Color 1
Flash Flash Flash Color 2 Flash Color 1 Flash Color 3 Flash Color 3
Steady ON - Steady ON Color 1 Steady ON Color 1
Steady ON Color 2 Steady ON Color 1 Steady ON Color 2
- Steady ON Steady ON Color 2
Steady ON Color 1 Steady ON Color 2 Steady ON Color 1
Steady ON Steady ON Steady ON Color 2
Steady ON Color 1 Steady ON Color 3 Steady ON Color 3
Cruise Flash
Flash Color 2/Cruise
Color 1 during OFF
cycle of Flash
Flash Color 1/Cruise
Color 2 during OFF
cycle of Flash
Cruise Steady ON Steady ON Color 2
Steady ON Color 1
Flash Steady ON Steady ON Color 2
Steady ON Color 1
