PMX-8UBT User’s manual
4. SPECIFICATIONS
Input Impedance Hi-Z 2.2 Kohm
Lo-Z 600 ohm
Mic 600 ohm
Line 2.2 kohm
Tape In 47 kohm
Equalizaon HIGH: +/- 12 dB @ 12 kHz
LOW: +/-12 dB @ 80 Hz
7-Band Graphic EQ +/- 12 dB @ 60, 120, 360, 1k, 2,5k, 7k, 16kHz
Frequency Response 20Hz - 20KHz, +1dB/-3dB @ 1W
Harmonic Distoron (THD) <0.3% 20Hz - 20KHz @ 100W
Aenuaon PAD -20dB
RMS Power 150W + 150W RMS @ 4 Ohm
Peak Power 300W + 300W max. @ 4 Ohm
Output Impedance 4 Ohm min.
Phantom Power +48Vcc
Mains Voltage AC 220-230 Vac / 50 Hz
Dimensions (WxHxD) 440 x 255 x 240 mm - 17.32 x 10.04 x .45 in
Weight 9.0 kg - 19.84 lbs.
5. INSTALLATION
5.1 Cable Connections
You will need several cables for the various connecons to and from the console. See
the pictures below that show the internal wiring of these cables. Be sure to use only
high quality cables.
5.1.1 Audio connections
Use commercial RCA cables to wire TAPE IN and REC OUT.
You can, of course, also connect unbalanced equipment to the inputs / outputs bal-
anced. Use either mono and stereo jack, making sure ring and collar are connected
together (or pins 1 & 3 in the case of XLR connectors).
WARNING! Never use unbalanced XLR connectors XLR (pin 1 & 3 connected) on
MIC input connectors when you are using phantom power.
