PMX-8UBT User’s manual
meets the required safety standards. Blown fuses must be replaced with fuses of the
same type and specicaon.
Make sure that all units must be properly grounded. For your safety, you should
never remove any ground connector from electrical devices or power cables, or
make them inoperave.
2. CHARACTERISTICS
(1) LEVEL
It adjusts the level of the channel signal in the main
mix.
(2) PAN
It controls the posion of the signal within the stereo
image. This control provides a constant-power charac-
terisc, which means the signal is always maintained
at a constant level, regardless of the posion in the
stereo.
(3) AUX SEND FX
It sends the audio signal to the internal DSP or exter-
nal eects devices. The AUX SEND FX knob adjusts the
volume level of the signal sent to this auxiliary bus.
If you want to use the internal eect, EFF SEND OUT
and RETURN connectors should not be used.
You can also connect an external eect processor to
the EFF SEND OUT and RETURN connectors; in this
case the internal eects module will be muted.
EQUALIZATION
All input channels have a 2-band equalizer. All bands
provide a boost or a cut of up to 12 dB. In the central
posion, the equalizer has no eect.
The high band (HIGH) and the lower band (LOW) have
“shelving” lters that increase or decrease all frequencies above or below their cut-o
frequency.
(4) HIGH
The HIGH control in the EQ secon controls the high frequency range of the relave
channel, with a boost/aenuaon of ± 12 dB.
1
2
3
4
5
6
9
