PFM Subsonic Filter Control: This unique feature is legendary with its ability to fine tune
the bass response of any system. Why waste power on nasty subsonic information when
PFM Subsonic Filter Control can help you to clean things up?
Bass Output Control: The BX-12 has the ability to produce large amount of deep, mind
shattering bass without damaging your speakers. The Bass Output Control circuit allows
the BX-12 to maximize the bass output of any autosound audio system while restraining
destructive bursts.
THE OUTSIDE
Functions
DIGITAL BASS MACHINE
MAX. BASS CONTROL
BX-12
1
2
4
7. Power On LED.
5
6
7
3
PFM SUBSONIC
FILTER
BASS LEVEL
35Hz
80Hz min max
3a 3b
3a. The PFM Subsonic Filter Control: The BX-12 utilizers a PFM Subsonic Filter
Control which will help with speaker control and amplifier power management. This PFM
Subsonic Filter Control set with frequencies selections from 35Hz-80Hz. On most systems,
setting at 33Hz is fine. If you want to protect your speaker system even more, you should
try a higher frequency. Often a higher frequency actually sounds louder and cleaner.
3b. Bass Level Control
2. Outputs: These RCA connectors should be connected to the next component after the
BX-12, such as a crossover, equalizer, or amplifier. Just remember, the BX-12 should go
inline before a crossover.
1. Inputs: The inputs of The BX-12 use a balanced input circuit to help minimize induced
noise. The are also designed to handle very high signal voltages up to 15 volts.
5. Para-Bass Controls: These 2 knobs control the Para-Bass functions of the BX-12. The
SWEEP knob allows you to pick the center frequency that you want the BX-12 bass
restoration circuit to maximize. The WIDE knob adjusts how wide of a frequency range the
BX-12 will effect.
6. Bass Maximizer Indicator: These three LED indicators flashes when the bass
maximization circuit is activated.
4. Power Connector
3. Dash Remote Control
