Soundstream BX-12 - Electronic Connections and Wiring; Power Connection

Power connection
B+(12V) : Connect a red wire to the car battery or other power source.
REMOTE : Connect an orange wire to remote activating (12V DC)wire of car
stereo or equalizer.
GND : Connect a black wire to the car chassis for ground connection.
ELECTRONIC CONNECTIONS & WIRING
Red
Orange
Black
- 4 -
