Soundweb BLU-100 - Technical Specifications; Analogue Inputs; Analogue Outputs; Control Ports

7
Technical Specications
FRONT PANEL LED INDICATORS: Signal Clip, Signal Present, 48V (input only)
Other: Control link status and activity for Ethernet and RS-232
connections (COM); Device conguration status (STAT);
Error (ERR); Power/Locate (PWR)
ANALOGUE INPUTS: 12 electronically balanced on Phoenix/Combicon
removable screw connectors
Mic/Line Inputs: Nominal gain 0dB, electronically switchable up to +48dB,
in +6dB steps
Input Impedance: 3.5kOhm
Maximum Input Level: +20dBu with 0dB input gain, (+8dBu with 12dB gain)
CMRR: >75dB at 1kHz
Equiv. Input Noise (EIN): <-128dBu typ. with 150 Ohms source
Phantom Power: 48V nominal, selectable per input
A/D Latency: 37/Fs [0.77ms@48k]
ANALOGUE OUTPUTS: 8 electronically balanced on Phoenix/Combicon
removable screw connectors
Maximum Output Level: +19dBu
Frequency Response: 20Hz to 20kHz (+0.5/-1dB)
THD: <0.01% (20Hz to 20kHz, +10dBu output)
Dynamic Range: 108dB typ. (22Hz to 22kHz unweighted)
Output Impedance: 40 Ohms balanced and 20 Ohms unbalanced
Crosstalk: <-75dB
D/A Latency: 29/Fs [0.60ms@48k]
CONTROL PORTS: 12 inputs and 6 outputs
Control Input Voltage: 0 to 4.5v
Control Input Impedance: 4.7kOhms to +5V (2-wire mode) >1MOhm (3-wire mode)
Logic Output Voltage: 0 or +5V unloaded
Logic Output Impedance: 440 Ohm
Logic Output Current: 10mA source, 60mA sink
