Advanced Setup
This is normally done by the installer at initial installation.
Press NEXT
to advance
Press NEXT
to advance
Press NEXT
to advance
Page 18
Press NEXT
to advance
Continued
* ON is only available if the thermostat
is system powered.
NEXT
NEXT
NEXT
NEXT
OWNER'S MANUAL
S1-THEH21P5S
Use these buttons to
adjust the Cycles Per Hour
from 2 to 6.
d=no limit (zoning)
d1=d+no compressor
lockout (page 19).
Select backlight operation
when a button is pressed:
OFF: Never turns on.
2,4,6 or 8: Seconds back-
light will be on.
ON: Always on.*
Use these buttons to select
thermostat operation in
degrees C or F.
Use these buttons to
adjust the deadband
from 1 to 6 degrees
(page 19).
Enter advanced setup by sliding the Program Switch to
SET. When the clock is flashing, press the NEXT button for
5 seconds. Do not release the button until this screen
appears.
To Next Page
