DESCRIPTION OF OPERATION
MAX PUNCH
®
XD Knock-Out Tool is a tool that will punch stainless
steel knockouts in up to 10-gauge stainless steel electrical panels
in sizes from ½ inch to 2 inches in diameter. The use of a ½”
cordless drill and a set of die punches is required.
IDENTIFICATION
1. Handle
2. Large Draw Stud
3. Small Draw Stud
4. Input Shaft
5. Full Extension Red Line
6. Draw Stud Receiver
7. Marksman Layout Tool
8. Step Drill Bit
9. Die Cup & Cutter
10. 7/16” Nut Driver
6
1
8
2
3
5
9
4
7
Step one
Mark The Strut Line
5/8”
7/8”
1/4”
1
1/4
1
1/2
2
1/2
3
3
4
1/2
1
2
3/8”
1
5/8”
1/2
3/4
1
1
Alignment
window
10
