SP tools SP62012 - Resistance; Transistor Hfe Test; DC Voltage Measurement

9
Resistance
Range
Resolution
Accuracy
200Ω
0.1Ω
±0.8% of rdg ± 3 digits
2kΩ
1Ω
±0.8% of rdg ± 2 digits
20kΩ
10Ω
±0.8% of rdg ± 2 digits
200kΩ
100Ω
±0.8% of rdg ± 2 digits
2MΩ
1kΩ
±1.0% of rdg ± 2 digits
Maximum Open Circuit Voltage: 3.2V
Overload Protection: 250V dc or rms. Ac for all ranges.
Transistor hFE Test (0-1000)
Range
Test Range
Test Current
Test Voltage
NPN & PNP
0-1000
Ib=10µA
Vce=3V
DC Voltage Measurement
1. Connect the red test lead to the VΩmA jack and black test lead to the COM
jack.
2. Set the rotary switch at desired DCV position. If the voltage to be measured
is not known beforehand, set the range switch at the highest range position
and then reduce it until satisfactory resolution is obtained.
3. Connect test leads across the source or load being measured.
4. Read the voltage value on the LCD display along with the polarity of the red
lead connection
