60 SC-CF & SC-MP Service Manual
How To Replace The Spa Pack
When replacing a SC-CF or SC-MP spa pack, it is important to make
sure to turn power off before proceeding.
4• Disconnect power input cables.
5• Disconnect light cables, keypad
and temperature probe con-
nectors.
8• With wrenches, free the
board blades by removing
the 2 heater nuts.
7• Disconnect heater ground
cable.
Light
Keypad
Probe
6• Disconnect pressure switch
cable.
To Next Page
