Space Pak ESP-J Series User Manual

7
SECTION 2: SYSTEM INSTALLATION
NOTICE: Before proceeding with the installation, we
recommend reading through this section of the
manual for an overall understanding of the air
conditioning fan coil unit and air distribution system
component installation procedures.
Step 1: Locating the Unit
The fan coil unit may be installed in an unconditioned
space (as long as it is protected from the weather) such
as an attic, garage or crawlspace, or a conditioned space
such as a basement, closet or utility room (see dimen-
sions in Figures 2.2, 2.3 and 2.4).
When selecting a location, consider the location of the
unit in relation to the return air box or filter box as shown
in Figure 2.5. The return air duct should have at least one
90° bend to avoid unnecessary sound feedback to the
living space from the fan coil unit.
When selecting a location, consider the layout of the
plenum duct, supply tubing, refrigerant lines and conden-
sate drain line.
When installing the unit above a finished ceiling or living
space, install a secondary drain pan. Always follow local
code requirements.
FIGURE 2.1: MODEL ESP-J SPECIFICATIONS
FIGURE 2.2: UNIT DIMENSIONS AND CLEARANCES (inches)
Model
System
capacity
(Nom. Tons)
Suction
Line (O.D.)
Liquid
Line (O.D.)
Cond.
Drain
(FPT)
Return
Inlet
(Dia.)
Connections
Recommended
Condensing Unit
Nominal
Capacity
(MBH)
Min
SEER
ESP-2430J-V
ESP-3642J-V
ESP-4860J-V
2 - 2-1/2
3 - 3-1/2
4 - 5
Electrical
Characteristics*
230/60/1
230/60/1
230/60/1
7/8"
7/8"
7/8"
3/8"
3/8"
3/8"
3/4"
3/4"
3/4"
15"
19"
24"
24 to 30
36 to 42
48 to 60
13+
13+
13+
Model
System
capacity
(Nom. Tons)
Std. CFM
@ 1.2"
W.C.
Motor
HP
F. L .
Amps*
No. of
Rows
Deep
Blower
Flow
Control
Device
Ship.
Wt.
(lbs)
JJV
ESP-2430J-V
ESP-3642J-V
ESP-4860J-V
2 - 2-1/2
3 - 3-1/2
4 - 5
440, 550 3/4
3/4
3/4
5.6/2.8
7.6/4
10.6/5.4
6
6
6
TXV
TXV
TXV
105
123
144
135
170
210
660, 850
880, 1150
Coil
Wheel Dia. 115V/230V
and
Width
10" x 6"
10" x 6"
10" x 6"
*Unit includes optional conversion kit to 115V.
*Unit includes optional conversion kit to 115V.
