Space-Ray CB30-N5 - Page 49

Form 43471000
-48- May 2021
CONTROL COMPONENTS
Item No.
Part No.
Description
Qty.
15
03988150
Plastic Vacuum Air Tube, 15” long
1
16
42750000
Cabinet Assembly
1
17
42751000
Access Panel
1
18
42752000
Air Inlet Plate (Perforated)
1
19
42447000
Sight Glass
1
20
42837040
Kit, Air Switch, set @ 0.11” W.C., #NS2-0307-00
1
21
30383000
Relay, 24V SPST-NO (2-stage controls)
1
22
30279980
Transformer, AT120B1051
1
23
42709000
Terminal Block Shield
1
24
30281000
Terminal Block, EK-204
1
24a
30743000
Terminal Block, EL-3008 (2-stage controls)
1
24b
30738030
Thermostat Connection Block – 3 Pole (2-stage controls)
1
25
42759000
Electrode Bracket
1
26
30295000
Electrode PSE-GF1 (Igniter/Sensor)
1
27
30314070
Ignition Cable, 7” long
1
28
44010010
Kit, Spark Module – Fenwal #35-608711-034
1
29
42398040
Monitoring Light, Green
1
30
42398060
Monitoring Light, Red
1
31
42398050
Monitoring Light, Amber (2 each for 2-stage controls)
1
32
42757000
Restrainer Nipple, 5” long
1
33
44010250
Kit, Gas Valve – WR #36J23-203B1 Single Stage (natural gas)
1
33a
44010260
Kit, Gas Valve – WR #36J23-204B1 Single Stage (propane gas)
1
34
44010310
Kit, Gas Valve – WR #36J58-201B1 Two Stage (natural gas)
1
34a
44010320
Kit, Gas Valve – WR #36J58-202B1 Two Stage (propane gas)
1
35
42701000
Orifice Fitting – ½” NPT x 7/16-27
1
37
03259xxx
Orifice for CB20-50 (State Model & Gas Type for Size)
1
38
42700000
Main Burner
1
39
30148000
Universal Bushing, 7/8”
1
40
42755000
Burner Bracket Sub-Assembly
1
41
42753000
Burner Clamp
1
Labels / Manual
Item No.
Part No.
Description
Qty.
42
42785000
Label, Wire Diagram – Ladder (1-stage controls)
1
42a
42785030
Label, Wire Diagram – Ladder (2-stage controls)
1
43
42706000
Label, Wire Diagram – Connections (1-stage controls)
1
43a
42706020
Label, Wire Diagram – Connections (2-stage controls)
1
44
43471000
Installation and Operation Instructions (not shown)
1
45
43344050
Label, Gas Connector Warning
1
46
43470000
Label, Clearance to Combustibles
1
47
42848030
Label, Nameplate (1-stage controls)
1
47a
42848190
Label, Nameplate (2-stage controls)
48
42013000
Label, “Space-Ray” Logo
1
49
43470030
Label, Warning (residential)
1
50
42834000
Label, 120V Caution
1
51
42875000
Label, Warning
1
52
43470040
Label, Operating Instructions
1
53
43470050
Label, Caution/Attention
1
54
43470060
Label, Horizontal Venting
1
55
43269060
Label, 24V Thermostat Connection – (2-stage controls)
1
56
43269070
Label, Low/High Fire (2-stage controls)
1
