Form 43471000
May 2021 -7-
Draft Inducer Guard Kit, #43486000……QTY–1
(The Draft Inducer Guard Kit is an aluminum shield
mounted around the draft inducer (brackets and
screws included). This item and the Emitter Guard Kit
make up the Lower Mounting Kit, which must be used
in installations with mounting heights between 6 ft.
and 8 ft.)
C. Kit, 2-Stage Relay Board, Part #44195000
Contains:
Relay Board , #30709058……QTY–1
Enclosure, #30709059……QTY–1
Cord Connector – ½” , #30635040……QTY–2
D. Deflector Kit, Part #43504000
The Deflector Kit is available for use to reduce the
clearances to combustibles below the heater. Refer
to the Minimum Clearances to Combustibles Table in
Section 4.0) when using this Deflector Kit. Heater
must be mounted ONLY in the horizontal position
when using this kit.
