SPAL SHAVED-B - Optional Wiring Diagrams; Positive Output; Negative Output; Reverse Polarity Output

Each Kit Contains The Following Components
B
Y
R
T
T
A
E
Output From Receiver
87A
86
85
30
87
+ 12 VDC
FUSE
30
87A
87
85
86
Output From Receiver
Power Window
Motor
S
W
I
T
C
H
Y
T
B
A
T
E
R
85
86
30
87
Output From Receiver
87A
+ 12 VDC Output
+ 12 VDC
FUSE
Optional Wiring Diagrams
Positive Output
Negative Output
Reverse Polarity Output
T
B
A
T
Y
E
R
Output From Receiver
86
Ground Output
30
87A
87
85
GROUND
FUSE
+ 12 VDC
FOR POWER WINDOWS TWO RELAYS MUST BE PLACED BETWEEN THE SWITCH AND THE
WINDOW MOTOR. THE DASHED LINES INDICATE WHERE
THE WIRES MUST BE CUT.
(1) Receiver
(2) Remotes
(2) Wire Harnesses
Installation Instructions for SPAL Shaved Door Handle Kit
Shaved-40
This kit is designed to operate up to seven functions via the four-button remote control.
Channels 1 and 2 are Positive outputs used to open your drivers and passenger doors. Channels 3
through 7 are all negative outputs tht can be used ot operate power door locks, power door releases, truck
releases, control linear actuators, or roll power windows up or down, with an additional (external) relay.
(See Page 7)
**Proper wiring is critical to the correct operation of this product. Inspect all wiring to be certain of proper
connections, a quality ground, and appropriate fusing. Also check wire rounting, keeping wires away from
potential damage such as moving parts**
2 7
