12
7.
The ange of the bottom
pole will rest on the nut and
washer of frame plate.
NOTE:
Assemble pole to base as shown:
A. Place 4 washers (B2) onto the 4 pre-installed bolts so
they rest on the nuts.
B. Rest pole on the 4 washers (B2).
Allow 4 pre-attached bolts to pass through the 4 holes in
bottom pole ange.
Secure pole assembly to plate with washers (B2) and nuts
(B5) as shown.
B2
B2
B5
Cutaway Views
B2
A
2
B2
B5
B
TWO CAPABLE ADULTS REQUIRED
FOR THIS PROCEDURE. FAILURE
TO FOLLOW THIS WARNING COULD
RESULT IN SERIOUS INJURY AND/
OR PROPERTY DAMAGE.
WARNING!
To Next Page
