SPALDING NBA Arena - Section F: Stadium Pad and Final Setup; Stadium Pad Hardware

29
Item Qty. PartNo. Description
50 1 600077 Stadium Pad, Bottom
51 1 600078 Stadium Pad, Top
52 1 203124 Ground Stake
53 1 574090 Label, Height Adjustment and Moving
54 1 204872 Label, Height Indicator
Item Qty. PartNo. Description
P1 10 206011 Bolt, Carriage, 3/8-16 x 2.75” Long
P2 10 203041 Nut, Hex-Flange, 3/8-16
HARDWARELISTANDIDENTIFIER
Bolt, Carriage, 3/8-16 x 2-3/4
206011
#P1 (10)
203041
NUT, HEX FLANGE, 3/8-16
#P2 (10)
AC00001
STADIUM AND BOARD PAD HARDWARE CARD
AND/OR
9/16”
(2) Socket Wrenches and Sockets
Extension
(2) Wrenches
9/16”
TOOLS REQUIRED FOR THIS SECTION
SECTION F:STADIUMPADANDFINALIZINGSET-UP
