DaTong Wrench
ALL DIMENSIONS IN MM
1-6
6-30
30-120
120-400
0.1
0.2
0.3
0.5
Wrench Tools
Screw Driver
7.4 lb 0.7 lb
(3.4 kg) (0.3 kg)
10.2 lb
(4.6 kg)
14.6 lb
11 lb
(6.6 kg)
(5 kg)
4
Hand Control
(P11620)
8
Mast
12 Emergency Stop Button
1 **Base
3
Control Unit
(P16694)
7
Front Caster
(P16794)
Leg Opening Pedal
9
Boom
Emergency Lowering11
Combined
Weight of
82 lb
(37.3 kg)
2
Actuator
(P16815)
5 Spreader Bar
6
Rear Caster
(P16795)
10
** Heaviest detachable part
Prior to assembly, unpack and inspect all parts from the shipping carton.
Contact you dealer immediately if any parts are damaged or missing.
WARNING!
• NO modi cation of this equipment is allowed. It is unsafe to modify the
equipment from its original state. This product is deemed safe to use with
only the original parts as delivered. Unauthorized use of any modi ed
equipment may result in serious injury or death.
• DO NOT replace any components of the lift without consulting with
Span-America and must follow proper instruction from Span when replacing
any components.
• DO NOT service any parts of the lift while in use with a patient.
• It is NOT safe to load the equipment more than the indicated maximum safe
working load.
• IF any accessories with lower load capacity than the equipment itself is used,
DO NOT load the equipment more than the lowest maximum safe
working load.
• REMOVE the battery pack if the lift will not be used for some time, to prevent
battery leakage. PERIODICALLY check the battery pack and the charger
• This equipment DOES NOT consist of any materials or ingredients to
which patients are exposed, that may cause bodily harm or injury.
• Prolonged exposure or physical contact with any part of the equipment WILL
NOT cause skin irritation, allergic reaction, etc.
• Using accessories, detachable parts, or materials not described in the
instruction manual MAY RESULT IN SERIOUS INJURIES.
• Keep the equipment away from children and pets when in use. IT MAY
CAUSE SERIOUS INJURY OR DEATH.
• Keep the equipment away from any pests or pest infested area. Diseases
transferred from pests to the equipment MAY CAUSE SERIOUS ILLNESS
to patients upon contact.
• If the lift is exposed to the sun for long periods of time, be CAUTIOUS as the
surface of the lift may be hot.
• There are no risk if the lift is exposed to reasonably foreseeable
environmental conditions
• CAUTION! The controller contains parts and assemblies that could be
susceptible to damage by electrostatic discharge (ESD). To reduce
the likelihood of this, one should be grounded prior to using the controller.
• DO NOT use the lift on a inclined surface that is greater than 5°.
FEATURES & OVERVIEW
