SpaNet SV2 Installation & Technical Manual

SV Series Spa Controls
SV Series Overview
3
Mains Power
Terminal Block
Heater Connection
Terminal Block
Earth Bonding
Terminal
Fuse 1
(Phase 3 Loads)
Fuse 2
(Phase 2 Loads)
Fuse 3
(Phase 1 Loads)
Heater Tube
AMP Power Outlets
(230-240V AC)
for spa accessories:
circ, o /uv, air blower
3
jet pumps, auxiliaries
Coupling
(tail & nut)
Coupling
(tail & nut)
Wall Mount
Bracket
Wall Mount Bracket
Heartbeat LED
Low Voltage Connections
(12V)
keypads, lights, in-pool sensor
digital/analog expand ports
Mains Power
Cable Entry
Points
Mounting Foot
Heater Cover Plate
(remove to access
heater connections)
DIP Switch Bank
TM

SpaNet SV2 Specifications

General

Brand	SpaNet
Model	SV2
Category	Control Panel
Language	English
