Front light and fender assembly
Required tools:#
- Front light: 5mm Allen Key and 10mm open ended wrench
- Fender stays: 4mm Allen Key
Steps:
Place the fender under the fork bracket. The bracket must be between the two hooks.
Insert the bolt into the light through the fork bracket and fender, and tighten using the
Allen key from the front and
the wrench from the back
