Hardware Overview
The heart of this breakout is the RV-8803 Real Time Clock module from Micro Crystal. In this section we'll cover most of the features and characteristics
of the RV-8803 and this breakout but if you are looking for a more thorough synopsis of the RV-8803, take a look through the Application Manual . The
table below lists some of the operating characteristics of the RV-8803.
Characteristic Value
Operating Voltage Range 1.5V - 5.5V
Time Accuracy (Temp. Compensated -40° to +85°C) +/-3 ppm
Time Accuracy (Temp. Compensated +85° to +105°C) +/-7 ppm
Current Consumption 240 nA (Typ.) to 350 nA
I C Address 0x64
Power
There are two primary ways to power the SparkFun Real Time Clock Module - RV-8803 (Qwiic). The best and easiest way is through the Qwiic
Connectors on either side of the board. When used with any of our Qwiic-enabled boards or our Qwiic Shields, this voltage will be 3.3V. The other power
input is the 3.3V pin broken out. The board also includes a 3V 47mAh battery in the 12mm coin cell battery holder on the back for backup power.
SparkFun Qwiic Shield for Arduino Nano Hookup Guide
Hookup Guide for the SparkFun Qwiic Shield for Arduino Nano.
SparkFun Qwiic Shield for Thing Plus Hookup Guide
A short guide for assembling and using the SparkFun Qwiic Shield for
Thing Plus.
