Heads up! While the RV-8803 can accept an input voltage between 1.5-5.5V, the Qwiic system operates at 3.3V so it is recommended to power
the RTC with 3.3V or lower, especially if you are using it with other Qwiic devices.
Qwiic and I C Interface
The easiest way to use the Real Time Clock Module - RV-8803 (Qwiic) is with the Qwiic connect system. Just connect the board using a Qwiic Cable to
your microcontroller to start talking to it. Alternatively, you can solder to the I C pins broken out on the board. The 7-bit I C unshifted address is 0x32
(0110010b). This is a hardware set address and there are no alternate slave addresses for the RV-8803. If you need multiple RTC's on a single I C bus
you will need to use a multiplexer or mux like the Qwiic Mux Breakout - 8 Channel.
2
2 2
2
