Battery Clip
17
Remember highlighted components are polarized.
NOW WORK ON THE BOTTOM OF THE BOARD
Battery Clip: Turn the board over and align the battery clip with
the white footprint on the Weevil Eye’s back. Make sure the legs
stick through the board and that the part is laying flat. Solder the
battery clip’s legs into place from the top of the board.
BOTTOM OF BOARD
