Spartan TE256 - Default Set Point Schedules; Cooling and Heating Schedule Details

Revised Date: 2017/01/24
7
Default Set Point Schedules
COOL Sun Mon Tue Wed Thu Fri Sat
Sch. 1
6:00
26.0℃
6:00
26.0℃
6:00
26.0℃
6:00
26.0℃
6:00
26.0℃
6:00
26.0℃
6:00
26.0℃
Sch. 2
8:00
29.5℃
8:00
29.5℃
8:00
29.5℃
8:00
29.5℃
8:00
29.5℃
8:00
29.5℃
8:00
29.5℃
Sch. 3
18:00
26.0℃
18:00
26.0℃
18:00
26.0℃
18:00
26.0℃
18:00
26.0℃
18:00
26.0℃
18:00
26.0℃
Sch. 4
22:00
26.0℃
22:00
26.0℃
22:00
26.0℃
22:00
26.0℃
22:00
26.0℃
22:00
26.0℃
22:00
26.0℃
HEAT Sun Mon Tue Wed Thu Fri Sat
Sch. 1
6:00
21.0℃
6:00
21.0℃
6:00
21.0℃
6:00
21.0℃
6:00
21.0℃
6:00
21.0℃
6:00
21.0℃
Sch. 2
8:00
16.0℃
8:00
16.0℃
8:00
16.0℃
8:00
16.0℃
8:00
16.0℃
8:00
16.0℃
8:00
16.0℃
Sch. 3
18:00
21.0℃
18:00
21.0℃
18:00
21.0℃
18:00
21.0℃
18:00
21.0℃
18:00
21.0℃
18:00
21.0℃
Sch. 4
22:00
16.0℃
22:00
16.0℃
22:00
16.0℃
22:00
16.0℃
22:00
16.0℃
22:00
16.0℃
22:00
16.0℃
 Unoccupied Set Points: activated by occupancy contact; Cooling: 28.0℃/ Heating: 15.0℃
 When schedules are activated, refer to cooling/ heating set points according to current
schedule.
 When pause or stop schedules, refer to manual set point or latest set point as Cooling Set
Point and dead band for Heating Set Point deviation.
 Scheduled Cooling Set Point range: 10.0℃ ~ 37.0℃; Heating Set Point range: 4.5℃ ~ 32.0
℃; make sure to set heating lower than cooling set point to have proper controls.
