Spasciani RN - Marking Requirements and Label Examples

Pag. 23 / 80
1
Device categories: very high level protection (Zones 0 and 20)
G
Ex Atmosphere: suitable for area with explosive gases, vapors, mists and air mixtures
D
Ex Atmosphere: suitable for area in which explosive atmospheres due to dusts may form
Ex h
Type of protection offered by the non-electrical device
Ga
Equivalent level of device protection (EPL): Cat. 1G in Zone 0
Da
Equivalent level of device protection: Cat. 1D in Zone 20
IIC
Gas group IIC → Hydrogen (representative gas)
IIIC
Gas group IIIC

Flammable volatile, non-conductive and conductive dust
T6
Class of surface temperature of devices for Group II gases: ≤ 85°C
T85°C
Maximum surface temperature of devices for Group II dusts = 85°C
Tamb -30 +60°C
Reference temperature for Atex environment
AR19ATEX039X
Atex Certificate
“X”
This non-electric device is subject to special conditions for use: the effectiveness and reliability
of the device is guaranteed by following the instructions in the user manual.
WARNING
POTENTIAL ELECTROSTATIC CHARGING HAZARDS – – Read the user manual
ATTENTION!
All device components shall be cleaned only with wet cloths and antistatic products to not charge the
exposed surfaces. See par. 4.1 “Cleaning and disinfection”).
ATTENTION!
Operators who use Atex SCBA are advised, at any stage of use, to wear antistatic clothing and use non-
sparking tools.
ATTENTION!
Atex breathing apparatus must be worn and removed in the absence of an explosive atmosphere.
ATTENZIONE!
Always read this note and pay particular attention to par. 4.1 “Cleaning and disinfection”.
See the Configurator for all combinations of mask + demand valve + cylinder that can be supplied with Atex
certification.
10. TECHNICAL DATA
10.1. Technical data
Maximum operating pressure
300 bar
Alarm activation pressure
55±5 bar
Medium pressure
5.5 bar
Operating pressure
-30°C / +60°C
10.2. Weights / Dimensions
Description
HxLxD
Dimensions
(mm)
Approx. weight
(Kg)
RN with mask and 6 l 300 bar steel cylinder (charge)
310x660x220
15
RN with mask and 6.8 l 300 bar composite cylinder (charge)
310x660x220
10
RN with mask and 9 l 300 bar composite cylinder (charge)
310x660x220
12
RN T1 with mask and 6 l 300 bar steel cylinder (charge)
310x660x220
15
RN BIBO with mask and 2 x 6.8 l 300 bar composite cylinders (charge)
310x660x220
16
RN FR T2 with mask and 6 l 300 bar steel cylinder (charge)
310x660x220
13
RN FR with mask and 6 l 300 bar steel cylinder (charge)
310x660x220
15.5
RN FR with mask and 6.8 l 300 bar composite cylinder (charge)
310x660x220
10.5
