SpeakerCraft MZC-66 Quick Install Guide

Zone 1
Remote Room
ZONE 1 ZONE 2ZO NE 3 ZONE 4 ZONE 5ZO NE 6
SPEAKERS
EZ-PAD
SPEAKERS
EZ-PAD
MZC-66
Multi-Zone Controller
EXPANSION
PORT LOOP
SOURCE 1 SOURCE 2 SOURCE 3 SOURCE 4 SOURCE 5 SOURCE 6
SPEAKERS
EZ-PAD
SPEAKERS
EZ-PAD
SPEAKERS
EZ-PAD
SPEAKERS
EZ-PAD
Cat.5* 50 FT.
R Zone SpeakerL Zone Speaker
MODE Base
(Up to 6)
EZ-Pad
Zone 2
Remote Room
RCA-to-Mini Stereo Interconnect
DVD
MUTE
SAT
CD
PWR
BASS TREB
TNR
iPod
AUX
PLAY
ESCINFO
MENUGUIDE
SEL
MODE 3.1
Keypad
MODE Base
Adapter
(Up to 6)
PS-3.0
24V DC
Power Supply
(REQUIRED)
Powers up to
6 Adapters
Cat.5* 500 FT. MAX
*DB9 / RS232
Null Modem
Interface Cable
DB9
DB9
MODE Jukebox
Music Server
Cat.5* 50 FT. MAX
Internet
Connection
RF
Transmission
Wireless
Router
NEVO
SL
Remote
NOTE: The RSA-1.0
is powered through
the Expansion Port
from the MZC-66
Cat.5*
LRVLRVLRVLRVLRVLRV
LRV
R Zone SpeakerL Zone Speaker
*Refer to owners manual for detailed specifications
SW1:
RSA-1.0
RS232 Interface Adapter
CONTROL
PORT
EXPANSION
PORT LOOP
RS232
DATA I/O
IR
IN
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
ADDRESS
12VDC
HI LO
PROG RAMMIN G
IR
OFF ON
SW1:
RSA-1.0
RS232 Interface Adapter
CONTROL
PORT
EXPANSION
PORT LOOP
RS232
DATA I/O
IR
IN
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
ADDRESS
12VDC
HI LO
PROG RAMMIN G
IR
OFF ON
*PS-2.0
12V DC Power Supply
(Optional for each MODE
Base used over 250 ft.)
SL
Cat.5* 250 FT.
*DB9 / RS232
RSA-1.0RSA-1.0
To 3rd party device for control
and data feedback
To Zone 2 Connections on MZC

SpeakerCraft MZC-66 Specifications

Audio Specifications

rated power per channel	30 Watts, 20 Hz to 20 kHz
power per channel	45 Watts @ 1 kHz
total harmonic distortion	< 0.7 %
frequency response	20 Hz to 20 kHz +/- 1.5 dB
channel separation	> 50 dB @ 10 kHz
crosstalk between sources	> 65 dB @ 10 kHz
signal to noise ratio	> 95 dB

Power

power consumption	55 Watts
line ratings	120 VAC, 2.0A
rear panel fuse	T5AL 250V

Weight and Dimensions

width	17 inches (432 mm)
height	5-1/4 inches (133 mm)
depth	14-3/4 inches (375 mm)
weight	23 lbs (10.5 kg)
