SpeakerCraft V12 User Manual

SPECIFICATIONS
V12
Powered Subwoofer
12" Long Throw Treated Paper
Cone Woofer with Butyl Surround
250 Watts
28Hz - 150Hz
45Hz - 150Hz
RCA Line Level
Auto On, Anti-clipping Circuitry,
Detachable Power Cord, User
Accessible Fuse
Black Vinyl with Wood Grain
Finish
19"* x 15" x 16
1
⁄2"*
(483mm x 381mm x 419mm)
44lbs. (19.96kg)
System Configuration:
Woofer:
Power Output:
Frequency Response:
Crossovers:
Hook Ups:
Additional Features:
Cabinet:
Dimensions H x W x D:
Weight:
In our attempt to constantly improve our products, features and specications are subject to change without notice.
V10
Powered Subwoofer
10" Long Throw Treated Paper
Cone Woofer with Butyl Surround
120 Watts
32Hz - 150Hz
45Hz - 150Hz
RCA Line Level
Auto On, Anti-clipping Circuitry,
Detachable Power Cord, User
Accessible Fuse
Black Vinyl with Wood Grain
Finish
16
3
⁄4"* x 13
1
⁄4" x 16"*
(425mm x 337mm x 407mm)
35lbs. (15.88kg)
V8
Powered Subwoofer
8" Long Throw Treated Paper
Cone Woofer with Butyl Surround
80 Watts
45Hz - 150Hz
45Hz - 150Hz
RCA Line Level
Auto On, Anti-clipping Circuitry,
Detachable Power Cord, User
Accessible Fuse
Black Vinyl with Wood Grain
Finish
12
1
⁄2"* x 10
3
⁄4" x 15
1
⁄4"*
(318mm x 273mm x 388mm)
24lbs. (10.89kg)
940 Columbia Avenue, Riverside, CA 92507 | USA (800) 448 0976 Fax (951) 787 8747 International +1 951 787 0543 | www.speakercraft.com
LIT99008
* Add
13
⁄16"(21mm) for feet & 4"(102mm) for rear panel connectors
LIMITED TWO YEAR WARRANTY
SpeakerCraft Inc. warrants to the original retail purchaser only that this SpeakerCraft product will be free from defects in materials and workmanship for a
period of two years, provided the product was purchased from a SpeakerCraft Authorized Dealer.
Defective products must be shipped, together with proof of purchase, prepaid insured to the SpeakerCraft Authorized Dealer from whom they were pur-
chased, or to the SpeakerCraft factory at the address listed on this installation instruction manual. Freight collect shipments will be refused. It is preferable to
ship this product in the original shipping container to lessen the chance of transit damage. In any case, the risk or loss or damage in transit is to be borne by
the purchaser. If, upon examination at the Factory or SpeakerCraft Authorized Dealer, it is determined that the unit was defective in materials or workmanship
at any time during this warranty period, SpeakerCraft or the SpeakerCraft Authorized Dealer will, at its option, repair or replace this product at no additional
charge, except as set forth below. If this model is no longer available and can not be repaired effectively, SpeakerCraft, at its sole option may replace the
unit with a current model of equal or greater value. In some cases where a new model is substituted, a modification to the mounting surface may be required.
If mounting surface modification is required, SpeakerCraft assumes no responsibility or liability for such modification. All replaced parts and product become
the property of SpeakerCraft Inc. Products replaced or repaired under this warranty will be returned to the original retail purchaser, within a reasonable time,
freight prepaid.
This warranty does not include service or parts to repair damage caused by accident, disaster, misuse, abuse, negligence, inadequate packing or shipping
procedures, commercial use, voltage inputs in excess of the rated maximum of the unit, or service, repair or modification of the product which has not been
authorized or approved by SpeakerCraft. This warranty also excludes normal cosmetic deterioration caused by environmental conditions. This warranty will be
void if the Serial number on the product has been removed, tampered with or defaced.
This warranty is in lieu of all other expressed warranties. If the product is defective in materials or workmanship as warranted above, the
purchaser’s sole remedy shall be repair or replacement as provided above. In no event will SpeakerCraft be liable for any incidental or
consequential damages arising out of the use or inability to use the product, even if SpeakerCraft Inc. or a SpeakerCraft Inc. Authorized
Dealer has been advised of the possibility of such damages, or for any claim by any other party. Some states do not allow the exclusion
or limitation of consequential damages, so the above limitation and exclusion may not apply.
All implied warranties on the product are limited to the duration of this expressed warranty. Some states do not allow limitation on the
length of an implied Warranty. If the original retail purchaser resides in such a state, this limitation does not apply.
