Part # Qty. Part Description Part Specification
1
.
a
2 BB Pivot Bearing 6902 RS Series Bearing - 28mm O.D. x 15mm I.D. x 7mm Width
1
.
b
4 Dropout Pivot Bearing 688 Series Bearing - 16mm O.D. x 8mm I.D. x 5mm Width
1
.
c
2 Shock Link @ Frame Pivot Bearing 6800-2RS Series Bearing - 19mm O.D. x 10mm I.D. x 5mm Width
1
.
d
2 Shock Link @ Seatstay Pivot Bearing 6800-2RS Series Bearing - 19mm O.D. x 10mm I.D. x 5mm Width
1
.
e
2 BB Pivot Spacer Steel spacer - 20mm O.D. x 15mm I.D. x 4mm Width
1
.
f
6 Dropout Pivot Bearing Spacer Steel spacer - 13mm O.D. x 8mm I.D. x 1.5mm Width
1
.
g
2 Shock Link @ Frame Pivot Spacer Steel spacer - 16mm O.D. x 10mm I.D. x 2mm Width
1
.
h
2 Shock Link @ Seatstay Pivot Spacer Steel spacer - 16mm O.D. x 10mm I.D. x 2mm Width
Part # Qty. Part Description Part Specification Torque in*lb
2
.
a
1 BB Pivot Nut
Alloy Nut - 27.5mm O.D x 15mm I.D, 19mm socket
200-230
2
.
b
1 BB Pivot Axle
Chromoly Axle - 15mm O.D. (27.5mm Head O.D.) x 68.5mm Length, 6mm Allen Hex Head
2
0
0
-
2
3
0
B
2
.
c
2 Dropout Pivot Bolt Chromoly Bolt - 8mm O.D. x 26mm Length (shoulder - 17mm, threads - 9mm) 7
0
-
9
0
B
2
.
d
2 Shock Link @ Frame Pivot Bolt Chromoly Bolt - 10mm O.D. x 20mm Length (shoulder - 6mm, threads - 14mm) 1
2
0
-
1
4
0
B
2
.
e
2 Shock Link @ Seatstay Pivot Bolt Chromoly Bolt - 10mm O.D. x 20mm Length (shoulder - 6mm, threads - 14mm) 1
2
0
-
1
4
0
B
2
.
f
1 Upper Shock Eye Bolt Steel Bolt - M8 x 50mm, 6mm Allen Hex (Round) Head 180-200
2
.
g
1 Lower Shock Eye Bolt Steel Bolt - M8 x 50mm, 6mm Allen Hex (Square) Head 1
8
0
-
2
0
0
B
2
.
h
1 Upper Shock Eye Nut M8 Nut, Threadlock
2
.
k
2 Upper Shock Eye Washer M8 Washer
2
.
m
1 Lower Shock Eye Washer M8 Washer
B
=
B
l
u
e
L
o
c
t
i
t
e
r
e
q
u
i
r
e
d
Bearing Kit Parts
Bolt Kit Parts
NOTE: Bearing and Bolt Kits are available only through your local Specialized dealer. To retain your warranty and for your safety, all maintenance
should be performed by your local Specialized dealer.
