B = Blue Loctite required
Part #
1.a
1.b
1.c
1.d
1.e
1.f
1.g
1.h
Qty.
2
2
2
2
2
4
4
2
Part Description
BB Pivot Bearing
Dropout Pivot Bearing
S-Link @ Frame Pivot Bearing
S-Link @ Seatstay Pivot Bearing
BB Pivot Spacer
Dropout Pivot Bearing Spacer
Dropout Pivot Teflon Thrust Washer
S-Link @ Frame Pivot Spacer
Part Specification
6802 RS (Orange) Series Full Complement Bearing - 24mm O.D. x 15mm I.D. x 5mm Thick
6800-2RS (Orange) Series Full Complement Bearing - 19mm O.D. x 10mm I.D. x 5mm Thick
688 Series Bearing - 16mm O.D. x 8mm I.D. x 5mm Thick
688 Series Bearing - 16mm O.D. x 8mm I.D. x 5mm Thick
Alloy spacer - 20mm O.D. x 15mm I.D. x 3.0mm Thick, Chamfered
Alloy spacer - 15mm O.D. x 10mm I.D. x 4.5aamm Thick, Chamfered
Teflon Washer - 22mm O.D. x 15mm I.D. x 0.85mm Thick
Alloy spacer - 12mm O.D. x 8mm I.D. x 1.4mm Thick, Chamfered
1.k 4 S-Link @ Seatstay Pivot Spacer Alloy spacer - 12mm O.D. x 8mm I.D. x 1.4mm Thick, Chamfered
Torque in*lb
Part Specification
Part #
Qty.
Part Description
2.a
2.b
2.c
2.c
2.d
2.e
2.f
2.g
2.h
Alloy Axle - M14 Thread (23.5mm Head O.D.) x 64.5mm Shaft Length, 8mm Hex
Alloy Nut - M14 Thread x 23.5mm O.D, 17mm socket
(use 6-point socket only)
Alloy Bolt - M10 Thread x 23.6mm Shaft Length, 4mm Hex, Countersunk Head
Alloy Bolt - M10 Thread x 26.5mm Shaft Length, 4mm Hex
Steel Washer - 17mm O.D x 13mm I.D. x 0.3mm Thick
Alloy Nut - M10 Thread x 17mm O.D x 7.6mm Thick, 13mm Open Wrench
Alloy Axle - M8 Thread x 52.5mm Shaft Length, 4mm Hex
Alloy Nut - M8 Thread x 15.7mm O.D, 11mm Socket
(use 6-point socket only)
Alloy Bolt - M8 Thread x 18mm Shaft Length, 4mm Hex
BB Pivot Axle
BB Pivot Nut
Dropout Pivot Bolt (Alloy Frame)
Dropout Pivot Bolt (Carbon Frame)
Dropout Pivot Washer (Carbon Frame)
Dropout Pivot Nut (Carbon Frame)
S-Link @ Frame Pivot Bolt
S-Link @ Frame Pivot Nut
S-Link @ Seatstay Pivot Bolt (Alloy Frame)
1
1
2
2
4
2
1
1
2
200-230 B
120-140 B
120-140 B
70-90 B
70-90 B
2.h
2.k
2.m
2.n
2.o
2.p
2.q
Alloy Bolt - M8 Thread x 21mm Shaft Length, 4mm Hex
Alloy Nut - M8 Thread x 15mm O.D. x 7.6mm Thick, 13mm Open Wrench
Steel Washer - 14mm
O.D x 8mm I.D. x 0.3mm Thick
Steel Washer - 15mm O.D x 11.5m I.D. x 0.3mm Thick
Titanium Bolt - M6 Thread x 32.5mm Shaft Length, 4mm Hex
Alloy Nut - M6 Thread x 12.6mm O.D, 10mm Socket
(use 6-point socket only)
Alloy Bolt - M8 Thread x 34mm Shaft Length, 4mm Hex
S-Link @ Seatstay Pivot Bolt (Carbon Frame)
S-Link @ Seatstay Pivot Nut (Carbon Frame)
S-Link @ Seatstay Pivot Washer
(Alloy frame / Carbon Frame, bolt side)
S-Link @ Seatstay Pivot Washer
(Carbon Frame, nut side)
Lower (Rearward) Shock Eye Bolt
Lower (Rearward) Shock Eye Nut
Upper (Forward) Shock Eye Bolt (Alloy Frame)
2
2
2
2
1
1
1
70-90 B
60-70 B
70-90 B
70-90 B
2.q
Alloy Bolt - M8 Thread x 26.5mm Shaft Length, 4mm Hex
Upper (Forward) Shock Eye Bolt (Carbon Frame)
1
70-90 B
