A
C
B
The seatpost must be inserted into the
frame deep enough so the minimum
insertion/maximum extension (min/max)
mark, where applicable, on the seatpost is
not visible (A).
The seatpost must also be inserted into the
seat tube deep enough to meet or exceed
(B) the minimum measured insertion depth
required by the frame (C).
STEP 16 STEP17
