Technical Specifications
Type PA Amplifier with Music Sources
Model P - 30FACC P - 30FACD P - 60FACC P - 60FACD
Supply Main Voltage AC 115V/230V ,50/60Hz ±10% , Switchable
Music Max
45W 45W 90W 90W
Output power
RMS Rated 30W 30W 60W 60W
Outputs Speaker outputs: MOH output : ZONE outputs:
4Ω,8Ω,16Ω,25V,70V 8Ω 1Watt / 600Ω,1V balanced. 25V or 70V 4 zones + All
Line out:600Ω,1V
Inputs MIC-1:250Ω,1mV,balanced with phantom power selectable (Jump 1)
MIC-2:250Ω,1mV,balanced with phantom power selectable (Jump 2) See page 11
MIC-3:250Ω,1mV,balanced with phantom power selectable (Jump 3)
MIC-4:250Ω,1mV,balanced with phantom power selectable (Jump 4)
AUX:47KΩ,200mV,unbalanced.
TEL: 0.1~1V,600Ω,adjustable, balanced
Frequency response 60~15K Hz at ±3dB
Total harmonic distortion Less than1% at 1KHz, at rated power
Signal to noise ratio All Volume Controls C.C.W : 75dB below rated power.
MIC-1~MIC-4 : 60 dB below rated power
AUX : 70 dB below rated power
TEL : 70 dB below rated power
Tone Controls Bass : ±10 dB at 100Hz
Treble: ±10 dB at 10KHz
Controls MIC-1~MIC-4 volume controls
Line(AUX/Tuner/CD/Cassette) volume control
Master volume control
TEL input level control
MIC-1 VOX on/off switch
MOH output level control
Tone controls (Bass, Treble)
Zone1, Zone 2, Zone 3, Zone 4 and All zone
AC 115V / 230V Voltage Selector Switch.
Indicators Output level meter (3 LEDS)
AC power consumption 100 VA 100 VA 170 VA 170 VA
Priority (VOX) Priority level (Using for MIC-1, the XLR connector or phone jack)
TEL / Emer MIC-1 MIC-2 MIC-3 MIC-4 AUX / Tuner/ CD-Tape
3 2 1 1 1 1
Dimensions ( H x W x D ) 3.5”(H) x 16.9”(W) x 11.8”(D)
Weight Approx : 15.4 lbs Approx :15.4 lbs Approx : 18.7 lbs Approx : 18.7 lbs
Color Black
Mounting options Table top or, 19” rack mountable(Use # PBM-RK2 rack mount bracket)
Music Source TM-2 : FM / AM Digital Tuner
Unit
CP-2 : Auto-reverse cassette
player unit
TM-2 : FM / AM Digital
Tuner Unit
CD-2 : CD player unit
TM-2 : FM / AM Digital Tuner
Unit
CP-2 : Auto-reverse cassette
player unit
TM-2 : FM / AM Digital
Tuner Unit
CD-2 : CD player unit
CD-2 CD Player Unit
Type CD Player Unit
Model CD-2
Distortion < 0.1 %
S / N >80 dB
Output 850 mV
Functions Eject/stop, Pause/play, Next, Previous,
Power, Program, Random, Repeat.
TM-2 FM/AM Digital Tuner Unit with 20 Programmable Presets
Type FM / AM Digital Tuner Unit
Model TM-2
Tuning range FM: 87.5~108 MHz
AM: 522~1620 KHz
Sensitivity FM: 2ìV ( 26 dB S /N )
AM: 30ìV ( 20 dB S /N )
Frequency response 30Hz ~ 15 KHz (+1 / -3 dB)
Distortion < 1 %
S / N >63 dB (1 mV, FM )
Output 500 mV (0~1V adjustable)
Functions FM/AM, Down, Up, Scan, Mem
M1, M2, M3, M4, M5, Shift
CP-2 Auto-Reverse Cassette Player Unit
Type Auto-Reverse Cassette Player Unit
Model CP-2
WOW / Flutter ≦ 0.45 %
Tape Speed 2940 ~ 3090 Hz
Frequency response 125Hz ~ 6.3KHz ± 4dB
S / N ≧ 40 dB
Distortion ≦ 3 %
Output 500 mV (0~1V adjustable)
Functions Eject, Auto-reverse, Program
