RC601UK REMOTE CONTROL
4
LL100N, HV101 & LL300N
The following general guidance is applicable to: Spectra LL100N, HV101 & LL300N.
Manual Override
● Press the Manual Override button on the remote once and the self levelling system will be
turned o. The Laser will continue to rotate but the laser will no longer be outputting a level
datum.
● This mode is typically enabled when the laser is being used to do Gradients and Slopes (See
Gradients & Slopes section on page 6 for further details).
● Pressing the Manual Override button once more will turn the self levelling system back on.
The Laser head will stop and adjust to a level datum and then begin rotating at 600rpm. The
laser is now running in self levelling mode once more.
Up / Down / Left & Right Arrows
● When the LL100N, HV101 or LL300N is in manual mode (Self levelling system has been
turned o), the Up / Down / Left & Right arrows are used to tilt the laser prism in either the X
or Y axis to set a progressive fall or gradient. (See Gradients & Slopes section on page 6 for
further details).
Grading
● The LL100N, HV101 & LL300N are all DUAL GRADE facility laser levels when using the Remote
Control. This means that they can be switched to “Manual” (to override the self levelling
system) allowing the user to set a grade (incline/slope) in the X axis only, Y axis only or both
together. The maximum settable slope is an approx. fall of 1m over 10m.
● For X & Y alignment, please see the case markings on the TOP of the laser head where sights
point in the direction of the axis being set.
