RC601UK REMOTE CONTROL
5
LL100N, HV101 & LL300N
The following general guidance is applicable to: Spectra LL100N, HV101 & LL300N.
Setting Single Axis Slope
● This example sets a grade in the X axis.
● Press the ON/OFF button once and the Laser will power on and begin automatically self-
levelling.
● Press the Manual Override button on the remote once and the self levelling system will be
turned o & the red HI / MAN LED illuminates and begins ashing.
● Using the black Left & Right Arrow buttons on the remote, set the % slope (fall) required - as
measured on your sta.
● When complete, press the Manual Override button once more and this will turn the self
levelling system back on. The Laser head will stop and adjust to a level datum and then begin
rotating at 600rpm. The laser is now running in self levelling mode once more.
Setting Y Axis Slope
● This example sets a grade in the Y axis.
● Press the ON/OFF button once and the Laser will power on and begin automatically self-
levelling.
● Press the Manual Override button on the remote once and the self levelling system will be
turned o & the red HI / MAN LED illuminates and begins ashing.
● Using the yellow Up & Down Arrow buttons on either the face of the laser or on the remote,
set the % slope (fall) required - as measured on your sta.
● When complete, press the Manual Override button once more and this will turn the self
levelling system back on. The Laser head will stop and adjust to a level datum and then begin
rotating at 600rpm. The laser is now running in self levelling mode once more.
Setting Both X & Y Axis Slopes (Dual Grade)
● Proceed as above, but use all four Arrow buttons on the remote - as required.
