2.7 Ethernet Port
Ethernet PortEthernet Port
Ethernet Port
Connector: RJ45 (Eth)
Pin Signal Description
1 TX+ Transmission signal plus
2 TX- Transmission signal minus
3 RX+ Reception signal plus
4
5
6 RX- Reception signal minus
7
8
Characteristics:
- Interface 10 Base T / 100 BASE T, IEEE-802.3 compliant
- Full featured auto negotiation function
- IP address assignment: DHCP automatic assignment or fixed IP address
- Protocol: Transfer Control Protocol and Internet protocol (TCP/IP)
- Web page server with HTTP protocol for configuration; status included
- Configuration and status are manageable through SNMP protocol. The MIB includes a
sub-set of configuration and status parameters. SNMP traps are sent to the network on
event trigger.
2.8
2.82.8
2.8 Operating Environment
Operating EnvironmentOperating Environment
Operating Environment
- Operating temperature: -5 to 60°C
- Storage temperature: -40 to 85°C
- Relative humidity: 95 % non-condensing
- Electromagnetic compatibility: in accordance with EN61000/EN55022/EN60950
2.9
2.92.9
2.9 EMC
EMCEMC
EMC
Complies with the requirements of the standards:
• EN 61000-6-2: ed 2005
• EN 61000-6-3: ed 2007
• EN55022 ed 2006 Class B
