DRINKING WATER SYSTEMS PLUMBING CONNECTIONS (cont.)
3/8" BLUE TUBING FROM TEE
FITTING OUT TO TANK
3/8" BLUE TUBING FROM ELBOW
FITTING OUT TO FAUCET
1/4" YELLOW TUBING FROM
UNION FITTING AT END OF RED
TUBING OUT TO SHORT BARB
FITTING ON AIR GAP FAUCET
REAR VIEW
TOP VIEW
FRONT VIEW
DWS-90 CONNECTIONS
2
1
2
1
3/8" BLACK TUBING
CONNECTS FROM
LONGER BARB TO
DRAIN SADDLE
AIR GAP FAUCET
CONNECTIONS
