18
TECHNICAL SPECIFICATIONS
SPA250Z SPA2100Z SPA450Z
Peak Power Output
At 4 Ohms load / 14.4V (THD<=1.0%)
All channels driven simultaneously 58W x 2 130W x 2 50W x 4
Rated Power Output (RMS)
At 4 Ohms load / 14.4V (THD<=0.3%)
All channels driven simultaneously 48W x 2 110W x 2 42W x 4
Rated Power Output (RMS)
At 2 Ohms load / 14.4V (THD<=0.3%)
All channels driven simultaneously 72W x 2 159W x 2 59W x 4
Rated Power Output (RMS)
At 4 Ohms load / 14.4V (THD<=0.3%)
All channels driven simultaneously 120Wx1 300W x 1 90Wx2
bridged bridged bridged
Damping Factor
All Channels stereo @ 4Ohms/100Hz > 50 > 50 > 50
Signal-to-Noise Ratio
(A-weighted - all channels) > 85 dB > 85 dB > 85 dB
Frequency Response
(all channels, frequency filtering
controls deactivated, 0 dB / - 1 dB) 20 Hz - 20 kHz 20 Hz – 20 kHz 20 Hz – 20 kHz
Channel Separation
(all channels) > 50 dB > 50 dB > 50 dB
Input Sensitivity
(all channels) 200 mV – 5.0 V 200 mV – 5.0 V 200 mV – 5.0 V
Integrated Active Filtering
X-Over Slope Rates 12 dB / oct. 12 dB / oct. 12 dB / oct.
Cross-Over Frequency
Swichable High & Low Pass 65/85/125 Hz 65/85/125 Hz 65/85/125 Hz
Fuses 1 x 20A ATC 2 x 20A ATC 1 x 30A ATC
Dimensions (W x D x H) mm 251 x 155 x 55 251 x 259 x 55 251 x 228 x 55
