REAR PANEL
14 FUSE
An ATC fuses for protection of the amplifier electronics against overload or wrong
operation
15 POWER INPUT TERMINAL "+ 12 V"
Terminal to connect the amplifier to the positive +12V pole of the car battery
16 POWER INPUT TERMINAL "GND"
Terminal to connect the amplifier to the negative or ground pole of the vehicle
17 REMOTE INPUT TERMINAL
Terminal to connect the amplifier to the automatic (remote) turn-on / turn-off lead of
the head unit
18 SPEAKER OUTPUT TERMINALS
Output terminal to connect the speakers in stereo or bridged mode to the amplifier
