TECHNICAL SPECIFICATIONS SPA2200 SPA4200
Rated Power Output (RMS)
At 4 Ohms load / 13.8V (THD<=0.1%)
All channels driven simultaneously 57Wx2 54Wx4
Rated Power Output (RMS)
At 4 Ohms load / 13.8V (THD<=1%)
All channels driven simultaneously 60Wx2 57Wx4
Rated Power Output (RMS)
At 2 Ohms load / 13.8V (THD<=1%)
All channels driven simultaneously 75Wx2 79Wx4
Rated Power Output (RMS)
At 4 Ohms load / 13.8V (THD<=0.1%)
All channels driven simultaneously 137Wx1 Bridged 133Wx2 Bridged
Damping Factor
All Channels stereo @ 4Ohms/100Hz > 110 > 110
Signal-to-Noise Ratio
(All channels) > 89 dB > 89 dB
Frequency Response
(all channels, frequency filtering
controls deactivated) 10Hz - 50 kHz (+0 dB / - 1 dB)
Channel Separation
(all channels) > 60 dB
Input Sensitivity
(all channels) 200 mV - 4.3V
Integrated Active Filtering
Slope Rates 12 dB /octave
Cross-Over Frequency
High Pass continuously variable 10 - 400 Hz
Low Pass continuously variable 40 - 400Hz
Fuses 1 x 25A ATC 1x40A ATC
Dimensions (W x H x D) 215 x 55 x 280 mm 360 x 55 x 280mm
